XINYUHAI has developed different series of servo motors for high-precision CNC machine tools. There are mainly three series: SY series universal servo motor, S1 series 5-pole high-speed servo motor and ZYH series high speed spindle motor. Servo motors and spindle servo motors have high cost performance, and are widely used in different types of CNC automation equipment, such as CNC lathes, CNC milling machines, turning centers, milling centers, CNC grinders, robots, automatic assembly lines, etc.
Get A Free Quote
Products List
HYM200- B4/B8
HYM200- B4/B8
Continuous thrust: 2666.6~5058.6N
Maximum thrust: 6571~13142N
Peak current: 28.8~57.6Arms
Maximum coil temperature: 100 ℃
Suction force: 10.7~21.4kN
HYM150- B4/B8
HYM150- B4/B8
Continuous thrust: 2128.4~4031.1N
Maximum thrust: 4928.2~10162.52N
Peak current: 28.8~57.6Arms
Electric coil temperature: 100 ℃
Suction force: 8.0~16.0kN
HYM100- B2/B4/B4
HYM100- B2/B4/B4
Continuous thrust: 379.4/758.7/1517.6N
Maximum thrust: 821.4/1642.7/3285.5N
Peak current: 14.4/14.4/28.8Arms
Maximum coil temperature: 100 ℃
Suction force: 1.3/2.7/5.4kN
HYM50- B1/B2/B4
HYM50- B1/B2/B4
Continuous thrust: 189.7/379.4/758.7N
Maximum thrust: 410.72/821.4/1642.7N
Peak current: 14.4/14.4/28.8Arms
Maximum coil temperature: 100 ℃
Suction force: 0.7/1.3/2.7kN
